Beckhoff EL34 Series User Manual

Commissioning
EL34xx 197Version: 1.5
Index 1App TxPDO-Map Status (for L1, pp = 00; L2, pp = 0A; L3, pp = 14)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Status PDO Mapping TxPDO UINT8 RO 0x0B (11
dec
)
1App:01 SubIndex 001 1. PDO Mapping entry (2 bits align) UINT32 RO 0x60n0:01, 1**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x03 (Overcurrent))
UINT32 RO 0x60n0:02, 1**
1App:03 SubIndex 003 3. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x04 (Inaccurate Voltage))
UINT32 RO 0x60n0:03, 1**
1App:04 SubIndex 004 4. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x05 (Inaccurate Current))
UINT32 RO 0x60n0:04, 1**
1App:05 SubIndex 005 5. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x06 (Voltage Guard Warning))
UINT32 RO 0x60n0:05, 1**
1App:06 SubIndex 006 6. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x07 (Voltage Guard Error))
UINT32 RO 0x60n0:06, 1**
1App:07 SubIndex 007 7. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x08 (Current Guard Warning))
UINT32 RO 0x60n0:07, 1**
1App:08 SubIndex 008 8. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x09 (Current Guard Error))
UINT32 RO 0x60n0:08, 1**
1App:09 SubIndex 009 9. PDO Mapping entry (6 bits align) UINT32 RO 0x60n0:09, 1**
1App:0A SubIndex 010 10. PDO Mapping entry (object 0x60n0 (PMX Sta-
tus), entry 0x10 (TxPDO Toggle))
UINT32 RO 0x00n0:00, 6**
1App:0B SubIndex 011 11. PDO Mapping entry (object 0x60n0 (PMX Sta-
tus), entry 0x10 (TxPDO Toggle))
UINT32 RO 0x60n0:10, 1**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1App TxPDO-Map Basic (for L1, pp = 01; L2, pp = 0B; L3, pp = 15)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Statistic
Basic
PDO Mapping TxPDO UINT8 RO 0x02 (2
dec
)
1App:01 SubIndex 001 1. PDO Mapping entry (object 0x60n1 (PMX Basic),
entry 0x11 (Voltage))
UINT32 RO 0x60n1:11, 32**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n1 (PMX Basic),
entry 0x12 (Current))
UINT32 RO 0x60n1:12, 32**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1App TxPDO-Map Power (for L1, pp = 02; L2, pp = 0C; L3, pp = 16)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Power PDO Mapping TxPDO UINT8 RO 0x04 (4
dez
)
1App:01 SubIndex 001 1. PDO Mapping entry (object 0x60n2 (PMX Power),
entry 0x11 (Active Power))
UINT32 RO 0x60n2:11, 32**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n2 (PMX Power),
entry 0x12 (Apparent Power))
UINT32 RO 0x60n2:12, 32**
1App:03 SubIndex 001 1. PDO Mapping entry (object 0x60n2 (PMX Power),
entry 0x13 (Reactive Power))
UINT32 RO 0x60n2:13, 32**
1App:04 SubIndex 002 2. PDO Mapping entry (object 0x60n2 (PMX Power),
entry 0x14 (Power Factor))
UINT32 RO 0x60n2:14, 32**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1App TxPDO-Map Energy (for L1, pp = 03; L2, pp = 0D; L3, pp = 17)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Energy PDO Mapping TxPDO UINT8 RO 0x03 (3
dec
)
1App:01 SubIndex 001 1. PDO Mapping entry (object 0x60n4 (PMX Energy),
entry 0x11 (Active Energy))
UINT32 RO 0x60n4:11, 64**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n4 (PMX Energy),
entry 0x12 (Apparent Energy))
UINT32 RO 0x60n4:12, 64**
1App:03 SubIndex 003 3. PDO Mapping entry (object 0x60n4 (PMX Energy),
entry 0x13 (Reactive Energy))
UINT32 RO 0x60n4:13, 64**
