Beckhoff EL7041-1000 User Manual

Commissioning
EL70x1134 Version: 4.4
Fig.149: Illegally exceeding the E-Bus current
From TwinCAT 2.11 and above, a warning message "E-Bus Power of Terminal..." is output in the logger
window when such a configuration is activated:
Fig.150: Warning message for exceeding E-Bus current
Attention
Caution! Malfunction possible!
The same ground potential must be used for the E-Bus supply of all EtherCAT terminals in
a terminal block!
