1.6 Non-reactive Bus Terminals
Note
Use of non-reactive Bus Terminals in safety applications
If a Bus Terminal is described as non-reactive, this means that the downstream terminal
behaves passively in a safety application (e.g. in the case of the all-pole switch-off of a po-
tential group).
In this case the terminals do not represent an active part of the safety controller and do not
affect the Safety Integrity Level (SIL) or Performance Level (PL) attained in the safety appli-
cation.
For details, please refer to chapter 2.17f in the TwinSAFE application manual.
Attention
Pay attention to the hardware version
Please pay attention to the information about the hardware version and non-reactivity of the
respective Bus Terminal in the chapters "Technical Data" or "Firmware Compatibility"!
Only terminals with the appropriate hardware version may be used without the attained SIL/
PL being affected!
The following tables show the designated non-reactive Bus or EtherCAT terminals at the time of the
preparation of this documentation with the corresponding hardware status
Bus terminal designation Hardware status
KL2408 05 - 07
KL2809 02
KL2134 09
KL2424 05
EtherCAT terminal designation Hardware status
EL2004 15 - 21
EL2008 07 - 13
EL2024 06 - 11
EL2034 06 - 07
EL2809 01 - 07
EL2872 01 - 07
EL7031 02 - 11
