Beckhoff EL7041-1000 User Manual

Mounting and wiring
EL70x1 65Version: 4.4
Connection (right-hand section of the housing)
Terminal point Name Signal
1' A1 Motor winding A
2' B1 Motor winding B
3' Sense A reserved, no connection permitted
4' Motor supply
+50V
Supply for output stages (maximum +50V
DC
)
5' A2 Motor winding A
6' B2 Motor winding B
7' Sense B reserved, no connection permitted
8' Motor supply
0V
Supply for output stages (0V
DC
)
