Beckhoff EP1957-0022 User Manual

Product description
EP1957-0022 and EP1957-222218 Version: 2.0.0
4.3 Technical data
The current certificates of all TwinSAFE products with the underlying standards and directives can be found
at https://www.beckhoff.com/en-en/support/download-finder/certificates-approvals/.
Product designation EP1957-0022 and EP1957-2222
Fieldbus EtherCAT
Number of inputs 8
Number of outputs 4
Input and output connections M12
Status display 12 (one green LED per input/output) + 5 diagnostic LEDs + 2 LEDs
for Us/Up + 2 LEDs for EtherCAT link/act
Response time
(read input/write to E-bus)
typical: 4ms (in default setting without local TwinSAFE logic),
maximum: see fault reaction time
Watchdog time adjustable from 2ms to 60s
Fault reaction time ≤ watchdog time
Cable length between sensor and EtherCAT Box Unshielded: max. 100m (0.75 or 1mm²)
Shielded: max. 100m (0.75 or 1mm²)
Output current of the clock outputs
(Input Power Mode parameter: diag test pulse)
typically 10mA
Output current of sensor supply
(Input Power Mode parameter: PowerMode A/B)
max. 250mA
Max. output current clock outputs/sensor supply in the event of
an error
max. 3A (the duration depends on the overtemperature-related
shutdown of the output driver)
Safe outputs max. 0.5A per channel
Diagnostic thresholds:
>4.7V -> high signal is detected
<1.0V -> low signal is detected
Input process image 7bytes
Output process image 7bytes
Supply voltage for the EP1957 24V
DC
(–15%/+20%)
Current consumption U
S
(wired with 8 potential-free contacts and 4 outputs)
12 channels occupied: typically 120mA
0 channels occupied: typically 100mA
(provide 4 A fuse)
Current consumption from U
P
(connected with 8 potential-free contacts and 4 actuators, without
load currents)
12 channels occupied: approx. 60mA
0 channels occupied: approx. 20mA
(provide 4 A fuse)
Power loss of the EtherCAT Box typically 4.7watts
Electrical isolation (between the channels) no
Electrical isolation (between the channels and EtherCAT) yes
Insulation voltage (between the channels and EtherCAT, under
common operating conditions)
Insulation tested with 500V
DC
Dimensions (WxHxD) 60(+0.5)mmx126(+0.5)mmx26.5mm
Housing material PBT+PET (Valox 855)
Sealing compound Polyurethane
Weight approx.315g
Permissible ambient temperature (operation) -25°C to +60°C
Permissible ambient temperature (transport/storage) -40°C to +85°C
Permissible air pressure (operation/storage/transport) 750hPa to 1100hPa
(this is equivalent to an altitude of approx. -690m to 2450m above
sea level assuming an international standard atmosphere)
Inadmissible operating conditions TwinSAFE EtherCAT Boxes must not be used under the following
conditions:
• under the influence of ionizing radiation (exceeding the natural
background radiation)
• in corrosive environments
EMC immunity/emission conforms to EN61000-6-2/ EN61000-6-4
Vibration/shock resistance conforms to EN60068-2-6/ EN60068-2-27
Shocks 15g with pulse duration 11ms in all three axes
Protection rating (when screwed together) IP67 (according to EN 60529)
Correct installation position variable
