Operation

EP1957-0022 and EP1957-222246 Version: 2.0.0

5.5.2 Status LEDs

Fig.30: Status LEDs

LED Display Meaning

In 1 on Input 1 is connected and logical 1

off Input 1 is not connected and logical 0

In 2 on Input 2 is connected and logical 1

off Input 2 is not connected and logical 0

In 3 on Input 3 is connected and logical 1
