Operation
EP1957-0022 and EP1957-222228 Version: 2.0.0
5.2.2.6 Characteristic curve of the inputs
The characteristic curve of the inputs is similar to type 3 according to EN 61131-2.
Fig.12: Characteristic curve of the inputs
5.2.2.7 Signal connection for outputs
The EtherCATBox has 4 safe outputs, each with a maximum output current of 0.5A.
Fig.13: Safe outputs 1 to 4
