Operation
EP1957-0022 and EP1957-222240 Version: 2.0.0
Index Name Default value/
unit
Description
8040:05 Module Fault Link active TRUE / Boolean If a module error occurs in this module, a module error is also set for
all other input modules of this TwinSAFE component for which this
parameter is also set to TRUE.
8040:0C Input Power Mode
(FSIN Module 1)
Diag test pulse /
ENUM
• Diag test pulse
• PowerMode A (Diag TestPulse active must be FALSE)
• PowerMode B (Diag TestPulse active must be FALSE)
see chapter Signal connection for inputs [}26]
8041:01 Channel1.InputFilterTime 0x000A / 0.1ms Input filter of the safe input. Following this time the internal input signal
changes to the applied signal state.
Internal test pulses can have a length of up to 2 ms.
8041:02 Channel1.DiagTestPulseFilter
Time
0x0002 / 0.1ms Input filter for the test pulse signal
8041:04 Channel2.InputFilterTime 0x000A / 0.1ms Input filter of the safe input. Following this time the internal input signal
changes to the applied signal state.
Internal test pulses can have a length of up to 2 ms.
8041:05 Channel2.DiagTestPulseFilter
Time
0x0002 / 0.1ms Input filter for the test pulse signal
8050:01-0C Parameters for FSIN module
2
see module 1 see module 1
8051:01-05 Parameters for FSIN module
2
see module 1 see module 1
8060:01-0C Parameters for FSIN module
3
see module 1 see module 1
8061:01-05 Parameters for FSIN module
3
see module 1 see module 1
8070:01-0C Parameters for FSIN module
4
see module 1 see module 1
8071:01-05 Parameters for FSIN module
4
see module 1 see module 1
