KL304x, KL305x 11Version: 4.0
2.4 KL304x, KL305x - Technical data
Technical data KL3041 KL3051 KL3042 KL3052 KL3044 KL3054
Number of inputs 1 2 4
Power supply for the sensors 24V
DC
via the power contacts
-
Signal current 0mA to
20mA
4mA to
20mA
0mA to
20mA
4mA to
20mA
0mA to 20mA 4mA to 20mA
Technology Single-ended
Internal resistance 80Ω + diode voltage 0.7V
Surge voltage resistance 35V max.
Resolution 12bit
Conversion time ~1ms ~2ms ~4ms
Measuring error (total mea-
suring range)
<±0.3% of the full scale
value
<±0.30% (at 0°C to
+55°C)
<±0.75% (when the ex-
tended temperature range
is used)
<±0.3% of the full
scale value
<±0.30% (at 0°C to
+55°C)
<±0.75% (when the
extended temperature
range is used)
Electrical isolation 500V (K-Bus / signal voltage)
Power supply for the electron-
ics
via the K-Bus
Current consumption from the
K-bus
typically 65mA
Bit width in the K-bus I/O Input: 1 x 16bits of data (1 x
8bit control/status optional)
Input: 2 x 16bits of data (2
x 8bit control/status op-
tional)
Input: 4 x 16bits of data (4 x 8bit control/sta-
tus optional)
Configuration No address or configuration settings
Weight approx. 70g
Dimensions (W x H x D) approx. 15mmx100mmx70mm (width aligned: 12mm)
Mounting [}13]
on 35mm mounting rail conforms to EN60715
Permissible ambient tempera-
ture range during operation
0°C ... + 55°C -25°C ... +60°C (extended
temperature range)
0°C ... + 55°C -25°C ... +60°C (ex-
tended temperature
range)
Permissible ambient tempera-
ture range during storage
-25°C ... + 85°C -40°C ... +85°C -25°C ... + 85°C -40°C ... +85°C
Permissible relative air hu-
midity
95%, no condensation
Vibration/shock resistance
conforms to EN60068-2-6/ EN60068-2-27, see also Installation instructions for enhanced mechanical
load capacity [}17]
EMC immunity/emission conforms to EN61000-6-2/ EN61000-6-4
Protection class IP20
Installation position variable
Approval
CE, cULus, ATEX [}24],
GL
CE, cULus, ATEX [}25],
GL
CE, cULus, ATEX
[}24], GL
CE, cULus, ATEX
[}25], GL
2.5 Basic function principles
The analog input terminals
KL304x process signals in the range from 0mA to 20mA
KL305x process signals in the range from 4mA to 20mA
with 12-bit resolution (4095 steps). The terminal inputs are single-ended inputs. The KL3041, KL3042,
KL3051 and KL3052 can supply the sensors with voltage supplied via the power contacts. The KL3044 and
KL3054 have no power contacts. The power contacts can optionally be supplied via the standard supply or
via a power feed terminal with electrical isolation.
The LEDs indicate the operating state of the associated terminal channels.
• green Run LED (omitted for KL3044 and KL3054):
◦ On: Normal operation
◦ Off: Watchdog-timer overflow has occurred. If no process data are transmitted by the Bus
Coupler for 100ms, the green LEDs go out.
• red Error LED:
