Description
TF5200 | TwinCAT 3 CNC
Online tool compensation
10 Version: 1.02
WEAR_CONST<expr> | WEAR_CONST_TOOL ACC_WEIGHT<expr> ] ]
RADIUS Radius compensation processing type
LENGTH Length compensation processing type (default)
TOOL_DIR Compensation in tool direction (5-axis) processing type
SURF_NORM_DIR Compensation in direction of surface normal (5-axis) processing type
DISC Discrete mode: input only via PLC, external presetting
CONT Continuous mode: Presetting values only by calculating the motion path
traversed and the wear constant, internal calculation
AUTO Automatic mode: Adding the external presetting and internal calculation
(default)
WEAR_CONST<expr> User-specific definition of wear constant; it acts modally, this means that
with #OTC ON the programmed wear constant is used and not the default
wear constant defined in the current tool data. Defining the valid wear
constant is optional.
Unit: 0,1 µm/m
WEAR_CONST_TOOL Switch to the default wear constant defined in the current tool data; it acts
modally, this means that with #OTC ON the default wear constant (default)
defined in the current tool data is used and not the user-specific definition of
the wear constant.
ACC_WEIGHT<expr> Acceleration weighting in percent [1;100], default: 100%
When OTC is deselected with #OTC OFF, the amount of wear (discrete and/or continuous) is in-
cluded in the calculation for the current tool.
