35
Displays / Error Messages
Function Message Cause
RCD
RCD
RCD
RCD
RCD
Rotary field
Rotary field
Rotary field
RCD has tripped at 345 ms. As trip time exceeds 300ms,
the RCD has failled!
Selective RCD has tripped at 219 ms. As trip time exceeds 200ms,
the RCD has failled!
The contact voltage exceeded the pre-set limit
Measurement therefore not carried out
The contact voltage exceeded the pre-set limit,
more than 100 V. Measurement therefore not carried out
The contact voltage exceeded the pre-set limit already during the
socket test. Measurement therefore not carried out
No rotary field is present or one voltage is out of specific. range
Rotary field (right) is present at L1, L2, L3
Rotary field (left) is present at L1, L2, L3
