31 MODEL D User Manual
7. 3 Command Examples
Note: All command parameters should be in hexadecimal format.
Note: A decimal to hex conversion table is shown below. If you are using the
MIDI Transpose command, then the 3rd column shows the MIDI IN Transpose that
corresponds to each data value. For example, if you wanted a transpose of +8 as
shown in the table above, then the data sent is 14 (hex).
Value Value (hex) MIDI Transpose
0 0 -12
1 1 -11
2 2 -10
3 3 -9
4 4 -8
5 5 -7
6 6 -6
7 7 -5
8 8 -4
9 9 -3
10 A -2
11 B -1
12 C 0
13 D 1
14 E 2
15 F 3
16 10 4
17 11 5
18 12 6
19 13 7
20 14 8
21 15 9
22 16 10
23 17 11
24 18 12
Function SysEX Command String
Set MIDI Channel to 13 F0 00 20 32 00 7F 0A 00 00 0C F7
Set Key Priority to last F0 00 20 32 00 7F 0A 01 00 02 F7
Turn on Multi Trigger F0 00 20 32 00 7F 0A 02 00 01 F7
Set Pitch Bend semitone to 11 F0 00 20 32 00 7F 0A 03 00 0B F7
Set MIDI IN Transpose to +8 F0 00 20 32 00 7F 0A 06 00 14 F7
Set Note C5 as Zero Volts F0 00 20 32 00 7F 0A 07 00 48 F7
Turn on Poly Chain F0 00 20 32 00 7F 0A 08 00 01 F7
Set Device ID to 5 F0 00 20 32 00 7F 0A 09 00 05 F7
Disable MIDI Channel Switches F0 00 20 32 00 7F 0A 0A 00 01 F7
Set Modulation Curve to Medium F0 00 20 32 00 7F 0A 0B 00 01 F7
