Behringer XENYX 1202FX User Manual

13 XENYX 1202FX/1002FX User Manual
5. Specications
Mono Inputs
Microphone Inputs
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance -132.7 dB / 137 dB A-weighted
@ 50 Ω source resistance -130 dB / 133.9 dB A-weighted
@ 150 Ω source resistance -127.1 dB / 130.9 dB A-weighted
Frequency response <10 Hz - 200 kHz (-1 dB)
Gain range +10 to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx. 2.6 kΩ balanced
Signal-to-noise ratio -107 dB / -111 dB A-weighted
(0 dBu In @ +22 dB gain)
Distortion (THD + N) 0.005% / 0.003% A-weighted
Line Input
Type ¼" TRS connector
electronically balanced
Impedance approx. 20 kΩ balanced
approx. 10 kΩ unbalanced
Gain range -10 to +40 dB
Max. input level +20 dBu @ 0 dB Gain
Fade-Out Attenuation
1
(Crosstalk Attenuation)
Main fader closed 85 dB
Channel fader closed 88 dB
Frequency Response
Microphone Input to Main Out
<10 Hz - 80 kHz +0 dB / -1 dB
<10 Hz - 137 kHz +0 dB / -3 dB
Stereo Inputs
Type ¼" TRS connector,
electronically balanced
Impedance approx. 20 kΩ bal. / 10 kΩ unbal.
(+4 dBu operating level)
approx. 20 kΩ bal. / 5 kΩ unbal.
(-10 dBV)
Max. input level +22 dBu
EQ Mono Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Audio Outputs
FX Send
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Main Outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Control Room Outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Headphones Output
Type ¼" TRS connector, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
Main Mix System Data
2
Noise
Main mix @ -∞, -105 dB / -108 dB A-weighted
Channel fader -∞
Main mix @ 0 dB, -94 dB / -97 dB A-weighted
Channel fader -∞
Main Mix @ 0 dB, -83 dB / -85 dB A-weighted
Channel fader @ 0 dB
FX Section
Converter 24-bit Sigma-Delta
Sampling rate 40 kHz
Mains Voltage
USA/Canada 120 V~, 60 Hz, MXUL6 adapter
U.K./Australia 240 V~, 50 Hz, MXUK6 adapter
Europe 230 V~, 50 Hz, MXEU6 adapter
China/Korea 220 V~, 50 Hz, MXCN6 adapter
Japan 100 V~, 60 Hz, MXJP6 adapter
Output 2 x 14.8 V~, 2 x 500 mA

Behringer XENYX 1202FX Specifications

General

Headphone out	Yes
Product color	Silver
Video capability	No
Equalizer bands quantity	3
Channel fader (1kHz)	88 dB
Digital sound processing	24 bit
Microphone input impedance	2600 Ω
Total Harmonic Distortion (THD)	0.005 %

Weight and Dimensions

Depth	242 mm
Width	220 mm
Height	47 mm
Weight	2100 g
