Behringer XENYX 1202FX User Manual

2 XENYX 1202FX/1002FX User Manual
Thank you
Congratulations! In purchasing our XENYX 1202FX/1002FX you have acquired
a mixing console whose small size belies its incredible versatility and
audioperformance.
The BEHRINGER XENYX mixing console oers you premium-quality microphone
preampliers with optional phantom power supply, balanced line inputs and
the ability to connect external eects processors. Because of its extensive and
carefully thought-out routing possibilities, your XENYX lends itself equally to
both live and studio use.
Table of Contents
Thank you .......................................................................2
Important Safety Instructions ...................................... 3
Legal Disclaimer ............................................................. 3
Limited Warranty ........................................................... 3
1. Introduction ............................................................... 5
1.1 General mixing console functions ............................... 5
1.2 The user’s manual ............................................................... 5
1.3 Before you get started ...................................................... 6
1.3.1 Shipment ......................................................................... 6
1.3.2 Initial operation ............................................................. 6
1.3.3 Online registration ....................................................... 6
2. Control Elements and Connectors .......................... 6
2.1 Mono channels .................................................................... 6
2.2 Stereo channels ................................................................... 7
2.3 Connector array of the main section ........................... 8
2.4 Main section ......................................................................... 8
2.5 Digital eects processor .................................................. 9
3. Applications ............................................................. 10
3.1 Recording studio ............................................................... 10
3.2 Live sound ........................................................................... 11
4. Installation ............................................................... 12
4.1 Mains connection ............................................................. 12
4.2 Audio connections ........................................................... 12
5. Specications .......................................................... 13

Behringer XENYX 1202FX Specifications

General

Headphone out	Yes
Product color	Silver
Video capability	No
Equalizer bands quantity	3
Channel fader (1kHz)	88 dB
Digital sound processing	24 bit
Microphone input impedance	2600 Ω
Total Harmonic Distortion (THD)	0.005 %

Weight and Dimensions

Depth	242 mm
Width	220 mm
Height	47 mm
Weight	2100 g
