11 XENYX 1202/1002/802/502 User Manual
4. Specications
Mono Inputs
Microphone Inputs (XENYX Mic preamp)
Type XLR connector, electronically balanced,
discrete input circuit
Mic E.I.N.
1
(20 Hz - 20 kHz)
@ 0Ω source resistance -134dB / 135.7dB A-weighted
@ 50Ω source resistance -131dB / 133.3dB A-weighted
@ 150Ω source resistance -129dB / 130.5dB A-weighted
Frequency Response
<10Hz - 150kHz -1dB
<10Hz - 200kHz -3dB
Gain range +10dB to +60dB
Max. input level +12dBu @ +10dB GAIN
Impedance approx. 2.6kΩ balanced
Signal-to-noise ratio 110dB / 112dB A-weighted
(0dBu In @ +22dB GAIN)
Distortion (THD+N) 0.005% / 0.004% A-weighted
Line Input
Type ¼" TRS jack, electronically balanced
Impedance approx. 20kΩ balanced,
approx. 10kΩ unbalanced
Gain range -10dB to +40dB
Max. input level +22dBu @ 0dB GAIN
Fade-Out Attenuation
2
(Crosstalk Attenuation)
Main fader closed 90dB
Channel muted 89.5dB
Channel fader muted 89dB
Frequency Response (Mic In  Main Out)
<10Hz - 90kHz +0dB / -1dB
<10Hz - 160kHz +0dB / -3dB
Stereo Inputs
Type ¼" TRS jack, electronically balanced
Impedance approx. 20kΩ
Max. input level +22dBu
Equalizer
EQ Mono Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
EQ Stereo Channels
LOW 80Hz / ±15dB
MID 2.5kHz / ±15dB
HIGH 12kHz / ±15dB
Send/Return
Aux Sends
Type ¼" TS jack, unbalanced
Impedance approx. 120Ω
Max. output level +22dBu
Stereo Aux Returns
Type ¼" TRS jack, electronically balanced
Impedance approx. 20kΩ balanced /
approx. 10kΩ unbalanced
Max. input level +22dBu
Outputs
Main Outputs
Type ¼" TRS jack, unbalanced
Impedance approx. 120Ω unbalanced
Max. output level +22dBu
Control Room Outputs
Type ¼" TS jack, unbalanced
Impedance approx. 120Ω
Max. output level +22dBu
Headphones Output
Type ¼" TRS jack, unbalanced
Max. output level +19dBu / 150Ω (+25dBm)
Main Mix System Data
3
(Noise)
Main mix @ -∞, -106dB / -109dB A-weighted
channel fader @ -∞
Main mix @ 0dB, -95dB / -98dB A-weighted
channel fader @ -∞
Main mix @ 0dB, -84dB / -87dB A-weighted
channel fader @ 0dB

Behringer Xenyx 502 Specifications

General

Inputs	5
Type	Analog
Channels	5
Inputs - Mic Preamps	1 x XLR
Outputs - Main	2 x 1/4"
Headphone Output	1 x 1/4"
EQ	2-band EQ
Phantom Power	Yes
Headphones Output	1
Weight	1.2 lbs
Outputs - Other	2 x RCA
Frequency Response	10 Hz
THD	<0.1%
Signal-to-Noise Ratio	110dB (A-weighted)
Power Supply	External power supply
Dimensions	1.85 x 5.9 x 7.0" / 47 x 150 x 177 mm
