Behringer Xenyx 502 User Manual

2 XENYX 1202/1002/802/502 User Manual
Thank you
Congratulations! In purchasing our XENYX 1202/1002/802/502 you have
acquired a mixing console whose small size belies its incredible versatility and
audioperformance.
The XENYX Series represents a milestone in the development of mixing console
technology. With the new XENYX microphone preamps including phantom power
as an option, balanced line inputs and a powerful eects section, themixing
consoles in the XENYX Series are optimally equipped for live and studio
applications. Owing to state-of-the-art circuitry your XENYX console produces
a warm analog sound that is unrivalled. With the addition of the latest digital
technology these best-in-class consoles combine the advantages of both analog
and digital technology.
Table of Contents
Thank you .......................................................................2
Important Safety Instructions ...................................... 3
Legal Disclaimer ............................................................. 3
Limited Warranty ........................................................... 3
1. Introduction ............................................................... 5
1.1 General mixing console functions ................................ 5
1.2 The user’s manual ............................................................... 5
1.3 Before you get started ...................................................... 5
2. Control Elements and Connectors ........................... 6
2.1 Mono channels .................................................................... 6
2.2 Stereo channels ................................................................... 7
2.3 Connector panel and main section ............................. 8
3. Installation ................................................................. 9
3.1 Mains connection ............................................................... 9
3.2 Audio connections ........................................................... 10
4. Specications ........................................................... 11

Behringer Xenyx 502 Specifications

General

Inputs	5
Type	Analog
Channels	5
Inputs - Mic Preamps	1 x XLR
Outputs - Main	2 x 1/4"
Headphone Output	1 x 1/4"
EQ	2-band EQ
Phantom Power	Yes
Headphones Output	1
Weight	1.2 lbs
Outputs - Other	2 x RCA
Frequency Response	10 Hz
THD	<0.1%
Signal-to-Noise Ratio	110dB (A-weighted)
Power Supply	External power supply
Dimensions	1.85 x 5.9 x 7.0" / 47 x 150 x 177 mm
