Loosen the screws 3 slightly.
–
Shift the holder 2 correspondingly.
–
Tighten the screws 3.
–
Swivel the corner knife station back again.
Correction of the corner incision at the seam beginning
–
Loosen the screw 5 slightly.
–
Adjust the corner knife station with the hexagon screw 4.
ATTENTION !
Observe the position of the eccentric.
Setting range
–
Tighten the screw 5.
–
Make a test seam.
–
Check seam and cutting pattern.
36
32
54
