Beisler 100-68 - Adjusting the Slant of the Corner Incisions

8.4 Adjusting the slant of the corner incisions
Caution: Risk of injury!
Switch the main switch off.
Adjust the corner knives only with the sewing unit switched off.
Standard and checking
The incisions of the corner knives should be as close to the seam as
possible (approx. 1 mm), but must not cut it.
–
Set the maximum sewing length at the control.
–
Sew a test seam.
It is advisable to iron a piece of interfacing on the workpiece
before. Thus the corner incisions are better visible.
–
Check seam and cutting pattern.
–
Loosen screw 6.
–
Adjust the corner knife holder 2 correspondingly.
–
Tighten screw 6.
–
Adjust the other three knife holders according to the seam pattern.
3
37
6
2
