9. Laser markings
According to the equipment the 100-68 is provided with 6 lasers for
marking the positioning points.
The following values are basic values:
1 : Needles
2 : Marking of the front positioning point
3 : Auxiliary positioning line for the production of men’s jackets
4 : Marking of the central positioning point
5 : Auxiliary positioning line for the production of men’s jackets
6 : Marking of the rear positioning point
3
39
1
2
3
4
5
6
