10.2 Dimensional drawing
Centrallubrication PICOwith integrated controlunit
Fig.43:
80 ±1
ca. 148
ca. 135
157± 2
124 ±1
111 ±1
pressure
connections Ø6
242 ±2
76 ±1
40
185 ±2
35 ±0,5
ca. 259
39 ±2
ø 128 ±1
9,5 ± 0,4
View
PICO-troniX1 with Hirschmann plug
View
PICO-troniX1 with bayonet plug
171 ±1,5
150 ±0,5
ca. 135
View
PICO-tronic with two Hirschmann plugs
