Belarus 1025/1025.2/1025.3 section А. Introduction

А3

International symbols

The manufacturer uses standard International symbols related to the use of devices

and controls. Symbols and their meanings are given below.

See Manual

Steering manipulation

Brake

Fast

Parking brake

Slowly

Signal

Forward

Emergency alarm

Back

- fuel

- battery charging

- cooling liquid

- cabin ceiling lamp

- pre-start heater plug

side lamps

- diesel speed

- turn lamp

- diesel oil pressure

trailer turn lamps

- diesel cooling fluid

temperature

- upper light
