Belden HIRSCHMANN EAGLE40-03 - Device Views EAGLE40-07; Front View

18
Installation EAGLE40
Release 02 08/2020
1.4 Device views EAGLE40-07
1.4.1 Front view
1 LED display element
2 2 × USB interface
3 5 × Gigabit Ethernet ports (RJ45) for 10/100/1000 Mbit/s Twisted pair connections
4 COM port (DB9 port)
5 CONSOLE port (DB9 port)
6 2 × SFP ports for 1000 Mbit/s fiber optic connections
1
2
3
4
6
5
