1.7.2 Port state EAGLE40-03
 Ethernet ports
These LEDs display port-related information. During the boot phase, they
indicate the status of the boot process.
The LEDs are directly located on the ports.
1.7.3 Device and port state EAGLE40-07
RR Router redun-
dancy
— None No router redundancy configured
Green Lights up The device is in the Router Redundancy
Master mode.
Flashing The device is in the Router Redundancy
Backup mode.
Display Color Activity Meaning
Link status — None Device detects an invalid or missing link
Green Lights up Device detects a valid link
Flashes 1 time a period Port is switched to stand-by
Flashes 3 times a period Port is switched off
Yellow Flashing Device is transmitting and/or receiving data
LED Display Color Activity Meaning
Power Supply voltage — None Supply voltage is too low.
Green Lights up The supply voltage is greater than 44 V DC.
Status Device status — None Device is powered off.
Green Lights up Device is not reporting any device status
alarms.
Red Lights up Device is reporting a device status alarm.
HDD Hard disk activity — None No data access activity
Yellow Flashing Data access activity
LTE LTE status — None No link is established.
Yellow Lights up Link has been established.
Flashing The connection is active.
LED Display Color Activity Meaning
POWER
STA
HDD
1
3
6
2
4
57
CONSOLE COM
