40
Installation EAGLE40
Release
02
08/2020
6 Technical data
General technical data
Digital input (optional)
Power consumption/power output
Dimensions
W × H × D
See “Dimension drawings” on page 41.
Weight EAGLE40-03 69.13 oz (1960 g)
EAGLE40-07 55.03 oz (1560 g)
Power supply
2 voltage inputs for redundant power supply
Safety extra-low voltage (SELV), redundant inputs disconnected
Nominal voltage DC 24 V DC ... 48 V DC
Voltage range DC 20 V DC ... 58 V DC
Connection type 6-pin terminal block
Input terminal block 18 AWG ... 24 AWG
(0.75 mm
2
... 0.2 mm
2
)
One individual conductor in a clamping
point.
DI port 18 AWG ... 24 AWG
(0.75 mm
2
... 0.2 mm
2
)
Grounding conductor at least 18 AWG (0.75 mm
2
)
Power consumption EAGLE40-03 max. 15 W
Power consumption EAGLE40-07 max. 25 W
Climatic
conditions
during
operation
Ambient air temperature -40 °F ... +158 °F (-40 °C ... +70 °C)
Storage/Transport temperature -40 °F ... +185 °F (-40 °C ... +85 °C)
Relative humidity (non-condensing) 10 % ... 95 %
Digital input
Maximum permitted input voltage range -32 V DC … +32 V DC
Nominal input voltage 24 V DC
Input voltage, low level, status “0” -0.3 V DC … +5.0 V DC
Input voltage, high level, status “1” +11 V DC … +30 V DC
Maximum input current at 24 V input voltage 15 mA
Input characteristic acc. to IEC 61131-2 (current-consuming) Type 3
Device name Maximum
power consumption
Power output
EAGLE40-033T1... 15 W 51 Btu (IT)/h
EAGLE40-03106... 15 W 51 Btu (IT)/h
EAGLE40-07... 25 W 58 Btu (IT)/h
