20
Installation EAGLE40
Release
02
08/2020
1.4.3 Left side view
1.5 Power supply
A 6-pin, screwable terminal block is available for the redundant supply to the
device.
For further information: See “Connecting the power supply and signal lines”
on page 31.
1.6 Ethernet ports
You can connect end devices and other segments to the device ports using
twisted pair cables or optical fibers (F/O).
You find information on pin assignments for making patch cables here:
See “Pin assignments” on page 21.
1 Save/Load/Reset button
