Installation EAGLE40
Release 02 08/2020
41
 Dimension drawings
Figure 7: Dimensions of the EAGLE40-03-3T1... device variants.
Figure 8: Dimensions of the EAGLE40-03-106... device variants.
7070
135.8135.8
187.2187.2
mmmm
inchinch
2.752.75
5.345.34
7.377.37
70
135.8
187.2
mm
inch
5.34
7.37
2.75
