42
Installation EAGLE40
Release
02
08/2020
Figure 9: Dimensions of the EAGLE40-07 device variants.
186
186
7.32
7.32
160
160
6.29
6.29
9
0.35
0.35
65
65
2.56
2.56
mm
mm
inch
inch
