Belkin AC1200 DB User Manual

1
What’s in the Box
AC1200 DB Wi-Fi Dual-Band AC+ Modem Router
Power Modem --- Combined power supply and ADSL Modem with
built-in bundled power and Ethernet cable attached to router
RJ11 telephone cable (attached to router)
Network information card (attached to router)
Belkin Setup CD with User Manual
Quick Setup Guide
Initial Setup
Where to Place Your Modem Router
For the best results, place the Router next to the master phone
socket (the first one where the phone line comes into the dwelling
from outside) in an open location away from large metal objects
and magnets such as those found in speakers. Raising the Router
above floor level can improve the strength of your wireless signal.
GETTING STARTED

Belkin AC1200 DB Specifications

General

Wireless Standard	IEEE 802.11ac
Frequency Bands	2.4 GHz, 5 GHz
Max Data Rate	1200 Mbps
Ports	1 x Gigabit WAN, 4 x Gigabit LAN, 1 x USB 2.0
Security	WPA, WPA2
Antennas	2 external antennas
