BELL+HOWELL DNV6HD - INSTALLING THE BATTERY; CHARGING THE BATTERY

4
1. Parts of the camcorder
1
TFT Touch Panel
2
Power button
3
Playback\Mode button
4
Rec \ Shutter button
5
Up\Display Off
6
Left \ IR On button
7
OK \ Menu button
8
Down
9
Right button
10
Jack Groove Cover
11
Lens
12
Wrist strap ring
13
Microphone
14
Compensating Light
15
Zoom in \Vol+ button
16
Zoom out\ Vol- button
17
Power Charging LED
18
Battery cover
19
Tripod socket
