Belray 96 - Physical Dimensions

–
4
–
[2] PHYSICAL DIMENSIONS
[unit : mm]
096-WK Wall Monut Type
220˚
600˚
1060
95
800
OPTION:
500 or 300
Horizontal Arm
is available.
300˚
1895
Min. 489
Max. 1589
Min. 879
Max. 1979
280
Max. 1190
Stroke : 1100
90
From 2004 July
