Bematech LR2000 User Manual

22
7 Specifications
Characteristics
Specification
Printing Property
Printing Method
Thermal Line printing
Resolution
180x180dpi (7 dots/mm)
Paper Width
79.5±0.5mm
Printing Width
72mm
Character Font
ASCII Font A：12X24
ASCII Font A：9X24
Printer Density
512dot/line
Printing Speed
250mm/s
NV bitmap Flash
64kb
Receipt Buffer
8kb
Communication
Interfaces
LR2000 - USB and Serial
LR2000E - USB, Serial and Ethernet
Power Adaptor
Input Voltage
AC 100～240V, 50/60Hz
Output Voltage
DC 24V，2.5A
Environment
Operating Temperature
0～45°C
Storage Temperature
-10～50°C
Operating Humidity
10-80%
Storage Humidity
10-90%
Life Span
Printer Head service lifetime
15,000,000 lines (100km)
Auto-cutter
1,000,000cuts
MCBF
60,000,000 lines
Physical
Characteristics
Dimensions (W x D x H)
5.75" x 7.75" x 5.88" (146mm x 197mm x 149mm)
Weight
3.4lb (1.54kg)
Note: Printer speed changes as the as the combination of the data transmission speed and control
command varies.

Bematech LR2000 Specifications

General

Cutter	Yes
Bluetooth	No
Flash memory	- MB
Product color	Black
Maximum resolution	180 x 180 DPI
Autocutter durability	1 million cuts
Operating temperature (T-T)	0 - 50 °C
Mean time between failures (MTBF)	60000000 h
I/O ports	Standard USB Type B, DB9, RJ45, RJ11, 3-pin with latch
USB connector	USB Type-B
Standard interfaces	RJ-11, RJ-45, RS-232, Serial
Serial interface type	RJ-11, RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Maximum roll diameter	710 mm
Supported paper width	79.5 mm
Type	POS printer
Character sets	ASCII
Print technology	Thermal
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	170-240 V
Power source type	AC

Weight and Dimensions

Depth	197 mm
Width	146 mm
Height	149 mm
