User’s Manual
10
Chapter 2
Technical Specifications
Specifications
Method: lines of thermal dots
Dot Density: 8 dots per mm
Width: 72 mm
Speed: 80 mm/s
Paper forward unit: 0.125 mm
Characters supported: CODE PAGE850, CODE PAGE 858,
CODE PAGE 860 and CODE PAGE 437
Code of bars supported: UPC-A, UPC-E, EAN13, EAN8, CODE
39, ITF, CODABAR, CODE 93, CODE
128, ISBN, MSI, PLESSEY, PDF0417.
Paper max width: 78 mm to 80 mm
Thickness: 50 to 120 g/mm
2
Max. Coil diameter: 65 mm
Type: KPH756 thermo script, manufactured
by VCP or equivalent
Polling force: 2N minimum
8 Kbytes
Serial: RS-232C
•Transmission rate: 9600 bauds
•Protocol: RTS/CTS
•Format: 8 bits without parity / 1 stop bit
Parallel (optional): Centronics
USB (optional): compatible 1.1 version
Voltage: 24 VDC
Consumption: Switched-off, 15 W
In operation: 35 W
Print head temperature (termistor), paper presence (phototransistor),
print head lifted (optical key).
Environmental storage conditions:
Temperature: 0ºC to 50ºC
Relative humidity: 10% to 95%.
Environmental storage conditions:
Temperature: -20°C to 70°C
Relative humidity: 10% to 95%
Height: 132 mm
Width: 152 mm
Depth: 196 mm
Head: Abrasion: 80 km exclusively for certified paper
(printing 20% of the line)
Cutter: 1.5 millions cuts (for certified paper of
56g/mm
2
)
Drawer
Mass: 1,2 kg
With Cutter: 1,3 kg
Cutting Options: Total or partial cut (option per way of activation ).
Characteristics
Printing
Features
Printing Paper
Entry Buffer
Communication Interfaces
Power Supply
Detection Functions
Environmental Conditions
Size
Life Expectation - MCBF
Power Activation
Mass
Cutter
