Bematech MP-2100 TH - Print Width, Character Width And Height; Barcodes

User’s Manual
20
Print Width, Character Width And Height
ASCII Dec Hex Description
DC2 18 12 Condensed mode (42 columns) off.
DC4 20 14 One-line expanded mode off.
ESC d n 100 64 Double height on (n=1) or off (n=0).
ESC H 72 48 48-column mode on (default).
ESC P 80 50 48-column mode on (default).
ESC SI 15 0F Condensed mode (64 columns) on.
ESC SO 14 0E One-line expanded mode on.
ESC V 86 56 One-line double height on.
ESC W n 87 57 Expanded mode on (n=1) or off (n=0).
SI 15 0F Condensed mode (64 columns) on.
SO 14 0E One-line expanded mode on.
Comand
GS h n
GS w n
GS H n
GS f n
GS k 0 d
1
...d
11
NUL
GS k 0 65 11d
1
...d
11
GS k 1 d
1
...d
6
NUL
GS k 66 6 d
1
...d
6
GS k 2 d
1
...d
12
NUL
Hexadecimal
Decimal
1D 68 n
29 104 n
1D 77 n
29 119 n
1D 48 n
29 72 n
1D 66 n
29 102 n
1D 6B 00 d
1
...d
11
00
29 107 0 d
1
...d
11
0
1D 6B 41 0B d
1
...d
11
29 107 55 11 d
1
...d
11
1D 6B 01 d
1
...d
6
00
29 107 1 d
1
...d
6
0
1D 6B 42 06 d
1
...d
6
29 107 66 6 d
1
...d
6
1D 6B 02 d
1
...d
12
00
29 107 2 d
1
...d
12
0
Description
Sets the height n of the barcode generated – each height unit corresponds
t a dot of 0.125 mm, so the final height is n x 0.125 mm where 1 - n
- 255. The default is n=162.
Determines the width of the barcode, where n=2 corresponds to nor-
mal width, n=3 is double width and n=4 is quadruple width. The
default is n=3.
Choose the position of the human readable information (HRI) of the
barcode.
n=0: No HRI
n=1: On top of the barcode (default)
n=2: On the bottom of the barcode
n=3: Both on top and on the bottom of the barcode.
Sets the font used to print the human readable information (HRI). The
default is n=0.
n=0 or n=48 – normal
n=1 or n=49 – condensed
Prints an UPC-A barcode where d
1
...d
11
is a sequence of 11 bytes
containing the barcode information with 48 -d -57.
Prints an UPC-E barcode where d
1
...d
6
is a sequence of 6 bytes containing
the barcode information with 48 -d -57.
Prints an EAN-13 barcode where d
1
...d
12
is a sequence of 12 bytes
containing the barcode information with 48 -d -57.
Barcodes
Barcodes are obtained using the GS command sequences show below. Please note that all parameters and
numbers are in decimal format, unless noted.
