MP-2100 TH · Revision 1.1
Appendix VI
Errors Signaling Table
In case an error occurs, it may be indicated through the LED PAPER. The quantity of LED blinks will indicate
a possible error. After the corresponding quantity of blinks to the possible error, a pause will occur. The blinks
and the pause are cyclical, according to the following table:
Error Quantity of blinks Possible Cause
Mechanism 3 Thermal head damaged or connection problem
of the mechanism with the controlling board.
Cutter 4 Cutter not operating.
Power supply 5 Power supply voltage below 20 V
Temperature 6 Thermal head temperature above safe conditions
