Bematech MP-2100 TH - Chapter 1 Presentation; Printer Description

User’s Manual
6
Printer Description
Explanations about how each MP-2100 TH part operates are described in this manual.
Whenever some note refers to one of the parts, the corresponding number of such part will be in brackets,
next to the note.
Chapter 1
Presentation
Figure 2
Front Cover
Back Cover
Front Cover opening knob
Base
PAPER key
ON LINE key
Led POWER
Led ON LINE
Led PAPER
Figure 1
DC Power Supply Connector
Drawer
Parallel Interface or USB (optional)
Figure 3
Serial Interface
