Bematech SB1015 - LCD Rear Display installation

25
4.2 LCD Rear Display installation *
1. Use USB cable to connect the second display and install VESA bracket set to the LCD display
with M4 screws (x4).
2. Remove the display mount cover from monitor.
3. Mount the LCD display assembly to the touch monitor and secure with screws. Plug USB
cable into monitor USB port.
* Optional peripheral
USB port
