Bematech SB9095 - Page 17

16
Note:
Do not plug in or unplug any connector except USB devices when the
power is on.
The current loading for all COM ports should not exceed DC 5V/3A and
DC 12V/2A。
JP8 - COM2 pin 9 voltage select
1-2 0V
Default = 0V
3-4 +5V
5-6 +12V
JP9 - COM1 pin 9 voltage select
1-2 0V
Default = 0V
3-4 +5V
5-6 +12V
JP12 - PS/2 Keyboard voltage setting
1-2 +5VSB
Default = 5VSB
2-3 +5V
JP13 - Cash drawer voltage setting
1-2 +24V
Default = +24V
2-3 +12V
