11
SEAT INSTALLATION
1. Open the box right side
up. Remove the accessories
first, then remove the unit
from the top as shown in
the diagrams above.
4. Place the wax ring and toilet
base and position the wax
ring on the flange. Remove
the access covers and cap
from the water inlet on the
back of the toilet. Align the
toilet over the flange and
bolts. Carefully lower the
toilet into the flange.
5. Secure the toilet base. Press
down evenly on the toilet
to set the wax ring. Install a
washer and nut onto each
bolt. Hand tighten the nuts.
Use a wrench to tighten the
nuts one quarter turn beyond
hand tight.
2. Prepare for installation by
removing the existing toilet
and cleaning the area near
the flange.
3. Place the installation guide
over the flange and mark
the perimeter with a
temporary marker.
To Next Page
