1268-600
VARIABLE SPEED JIGSAW
10
ASSEMBLY AND OPERATING
INSTALLING A BLADE
WARNING : Always remove the plug from the power source before installing or
removing a blade or adjusting the jig saw in any way.
1. To install a blade in the jig saw, push upward on the blade locking lever (1) (Fig. 1).
2. Insert the appropriate blade (2) into the blade slot (3) as far as it will go.
NOTE: Make sure the rear edge of the blade is nested in the blade guide roller (4).
3. Release the blade-locking lever.
NOTE: The blade will automatically be locked into the blade holder. Pull outward on
the blade to ensure it is properly locked into the blade holder.
REMOVING A BLADE
To remove a blade, simply push upward on the blade locking lever and remove the
blade from the blade holder.
Fig. 1
1
Fig
Fig
.
1
1
1
2
3
4
