Product Description
Parts List
Supply Voltage
Options
Caution
Caution
The EDS3065 Insulation Fault Location Device comprises the following components:
1 pc. Aluminium Case with Carrying Strap
1 pc. PGH185 Test Device
1 pc. EDS165 Insulation Fault Evaluator Unit, inclusive of accumulators
1 pc. PSA3020 Clamp-on Probe (diameter 12 mm)
1 pc. PSA3052 Clamp-on Probe (diameter 52 mm)
1 pc. Mains Cable
3 pcs. Safety Measuring Lead, black
1 pc. Safety Measuring Lead, green/yellow
4 pcs. Safety Claw Grip (3 x black, 1 x green/yellow)
1 pc. BNC Adapter / Banana Plug -> Transformer
2 pcs. Banana Plug
1 pc. Accumulator Charging Set
1 pc. TGH1266 Operating Manual
Before commissioning, please check that all the components listed above are included. Do not
undertake any work with an incomplete system. If any components are missing, please contact a
Technical Adviser at BENDER.
Two different EDS3065 Insulation Fault Location Devices are available. The difference between
them is the supply voltage for the PGH185 Insulation Fault Test Device:
• PGH185 - supply voltage: AC 230 V
• PGH185-13 - supply voltage AC 90 ... 132 V
Prior to commissioning, it is absolutely essential to check whether the supply voltage of the
EDS3065 system matches the voltage of the mains supply. Operation of the EDS3065 with the
wrong supply voltage can result in the destruction of the PGH185 Test Device.
When working with the EDS3065, only use those components which are supplied with the system.
In particular, do not use any other clamp-on probes, measuring leads or measuring terminals.
The EDS3065 represents a complete system. In addition to the PSA3020 and PSA3052 clamp-
on probes which are supplied with the system, measuring current transformers can be connected
to the EDS165 insulation fault evaluator. These may be BENDER Measuring Current Trans-
formers which are already installed in the system.
The following types of transformers are suitable:
Measuring Current Transformers, Model Series W1-S35 ... W5-S210
Rectangular Measuring Current Transformers, Model Series WR ...
Split-Core Type Measuring Current Transformers, Model Series WS ...
Important: normal commercial measuring transformers must not be used!
This also applies to additional clamp-on probes or measuring current transformers from the
BENDER range.
Attention: if transformers are not being used, they must not be left open in the system. In this case,
the transformer terminals k u. l should be shorted.
