Product Description
Technical Data
EDS3065
EDS3065 Insulation Fault Location Device
Insulation co-ordination acc. to IEC 664-1: dependent on the
current sensor used
Type of operation: continuous operation
PGH185 Insulation Fault Test Device
Rated insulation voltage: AC 500 V
Rated impulse withstand voltage/contamination level: 4 kV / 3
Monitored System
Operating range of Rated mains voltage, AC: 19.2 ... 575 V
Operating range of Rated mains voltage, DC: 19.2 ... 504 V
Supply Voltage
Supply voltage, U
S
: AC 230 V for PGH185
Operating range at AC 230V : 0.8 ... 1.15 x U
N
AC 90 ... 132 V for PGH185-13
Fuse protection for supply voltage: Fine-wire fuse, 100 mA, slow-acting
Measuring Cycle
Maximum test current: 25 / 10 mA
Test cycle: 2 s
Pause time 4 s
Type Tests
Test of electromagnetic compatibility (EMC):
Immunity against electromagentic interference acc. to EN 50 082
Emissions acc. to EN 50 081:
Emissions acc. to EN 55 011/CISPR11: Class B *)
Mechanical Tests
Shock resistance, to IEC 68-2-27: 15 g / 11 ms
Bumping acc. to IEC 68-2-29: 40 g / 6 ms
Vibration strength acc. to IEC 68-2-6: 10 .... 150 Hz / 0.15 mm - 2 g
Environmental Conditions
Ambient temperature during operation: -10 ... +55 °C
Ambient temperature during storage: -40 ... +70 °C
Climate class acc. to IEC 721: 3K5, but without dew and ice formation
General Data
Operating position: as desired
Type of connection: flexible safety leads with safety terminals
Set-up mode: upright, horizontal, or on metal parts with the use of magnetic strips
Protection class acc. to EN 50529: IP20
Weight: approximately 700 g
Dimensions, WxHxD: 160x148x81 mm
*) Class B devices are suitable for the use in industrial application as well as in house holds.
