DisplayDisplay
iso685-D-B_D00177_05_M_XXEN/07.2017
29
8.6 History memory
Up to 1023 alarm messages and device errors are stored in the history memory with date
and time stamp. When the history memory is deleted, the minimum insulation resistance
R
min
will also be reset at Menu/Data Measured values - Data insulation.
History 4.1
Insulation fault
11kΩ
28.03.14 17:0 2
28.03.14 17:18
8/8
Next message
Leave view
Fault description
Alarm value
Feault occured
Fault disappeared
Previous message
Number of selected
errors/
Total number of
error messages
8.7 Initial measurement
During the initial measurement, the device records all measured values.
All measured values that may have been recorded before will be discarded if a new initial
measurement is started.
IT System
R(an) 40kΩ/10kΩ
Initial
measurement
Initial
measurement
