Page #8 background imageLoading...
Page #8 background image
8
MK2007CBM_D00218_01_M_DEEN/10.2015
MK2007CBM(T)
Alle Rechte vorbehalten. Nachdruck und Vervielfältigung nur mit
Genehmigung des Herausgebers. Änderungen vorbehalten!
© Bender GmbH & Co. KG
All rights reserved. Reprinting and duplicating only with
permission of the publisher. Subject to change!
© Bender GmbH & Co. KG
Fotos: Bender Archiv. Photos: Bender archives.
Bender GmbH & Co. KG
Postfach 1161 • 35301 Grünberg • Germany
Londorfer Straße 65 • 35305 Grünberg • Germany
Tel.: +49 6401 807-0 • Fax: +49 6401 807-259
E-Mail: info@bender.de • www.bender.de
BENDER Group
Cable (twisted pair, shielded, shield connected to PE on one side).................................................
................................................................................................recommended: J-Y(St)Y min. 2 x 0.8
Terminating resistor .................................................................................................. 120Ω (0.5 W)
Device address, BMS-Bus...................................................................................................... 1…90
Factory setting device address..........................................................................................1 (Master)
General data
EMC immunity ..................................................................................... according to IEC 61000-6-2
EMC emission ...................................................................................... according to IEC 61000-6-4
Classification of climatic conditions IEC 60721
Stationary use...............................................................................................................................3K5
Transport ......................................................................................................................................2K3
Storage..........................................................................................................................................1K4
Operating temperature .............................................................................................. -5 … +55 °C
Classification of mechanical conditions IEC 60721
Stationary use..............................................................................................................................3M4
Transport......................................................................................................................................2M2
Storage.........................................................................................................................................1M3
Operating mode ..............................................................................................continuous operation
Mounting position ......................................................................................................... any position
Connection details ................................................................................................ plug-in terminals
Connection properties
rigid/flexible/AWG.....................................................0.2 … 2,5 / 0.2 … 2.5 mm² / 24-12 AWG
flexible, with ferrule without/with plastic sleeve ........................0.25 … 2.5 / 0.25 … 2.5 mm²
Two conductors with the same cross section
rigid/flexible ......................................................................................... 0.2 … 1 / 0.2 … 1.5 mm²
flexible, with ferrule without plastic sleeve.............................................................0.25 … 1 mm²
flexible, TWIN ferrules with plastic sleeve..............................................................0.5 … 1.5 mm²
Degree of protection, build-in (EN 60529)............................................................................... IP 50
Degree of protection, terminals (EN 60529) ........................................................................... IP 20
Enclosure ......................................................................................................... flush-mounting type
Mounting type.............................................................. flush-mounting, cable-duct, switch board
Flammability class ..............................................................................................................UL94 V-0
Weight ................................................................................................................................. ≤ 150 g
Leitung (paarweise verdrillt, geschirmt, Schirm einseitig an PE).....................................................
.......................................................................................................empfohlen: J-Y(St)Y min. 2 x 0,8
Abschlusswiderstand.................................................................................................. 120Ω (0,5 W)
Geräteadresse, BMS-Bus ....................................................................................................... 1
…90
Werkseinstellung Geräteadresse ......................................................................................1 (Master)
Allgemeine Daten
EMV-Störfestigkeit............................................................................................. nach EN 61000-6-2
EMV-Störaussendung ....................................................................................... nach EN 61000-6-4
Klimaklassen nach IEC 60721
Ortsfester Einsatz ..........................................................................................................................3K5
Transport.......................................................................................................................................2K3
Langzeitlagerung..........................................................................................................................1K4
Arbeitstemperatur ......................................................................................................-5 … +55 °C
Mechanische Beanspruchung nach IEC 60721
Ortsfester Einsatz ........................................................................................................................ 3M4
Transport..................................................................................................................................... 2M2
Langzeitlagerung........................................................................................................................ 1M3
Betriebsart .....................................................................................................................Dauerbetrieb
Einbaulage .............................................................................................................................beliebig
Anschlussart............................................................................................................... Steckklemmen
Anschlussvermögen (Versorgungsspannung, BMS-Bus
starr/flexibel/Leitergrößen.........................................0,2 … 2,5 / 0,2 … 2,5 mm² / 24-12 AWG
flexibel mit Aderendhülse ohne/mit Kunststoffhülse ..................0,25 … 2.5 / 0,25 … 2,5 mm²
Mehrleiteranschluss (2 Leiter gleichen Querschnitts)
starr/flexibel.......................................................................................... 0,2 … 1 / 0,2 … 1,5 mm²
flexibel mit Aderendhülse ohne Kunststoffhülse.....................................................0,25 … 1 mm²
flexibel mit TWIN-Aderendhülse mit Kunststoffhülse ...........................................0,5 … 1,5 mm²
Schutzart, eingebaut (DIN EN 60529) ....................................................................................... IP50
Schutzart, Klemmen (DIN EN 60529) ........................................................................................ IP20
Gehäusetyp .......................................................................................................... Unterputzgehäuse
Montage..................................................................................... Unterputz, Kabelkanal, Schalttafel
Entflammbarkeitsklasse .................................................................................................... UL94 V-0
Gewicht ............................................................................................................................... ≤ 150 g
