5. Initial measurement
During device start, all measured values are recorded.
Factory settings
Menu
Fact.
settings
Menu
Fact.
settings
Menu 6.1: HRG system Menu 6.5: Response values
1. U
sys (L-L)
400 V
4. < R
NGR
50 %
2. CD-NGRM CD1000
5. t
NGR trip
0 s
3. Frequency 50 Hz
6. Ground fault trip on
4. I
NGR nom
5 A
7. t
GF trip
5 s
5. R
NGR nom
470 Ω 8. Alarm stored on
Menu 6.2: CT
9. t
restart
5 s
1. CT primary 600
10. Restart count 2
2. CT secondary 1 11. Trip signal RMS
3. CT connection 50 mA 12. Upper limit harmonic 32
Menu 6.3: NGR
13. Lower limit harmonic 0
1. Method auto
Menu 6.6: System settings
2. PT primary 1 1. Ground-fault relay
Mode fail-safe
Rel. test on
3. PT secondary 1 2. NGR relay
Mode fail-safe
Rel. test on
Menu 6.4: Phase monitor
3. Trip relay
Mode fail-safe
Rel. test on
1. Phase monitor on 4. Analogue
Mode 4-20 mA
Function R NGR
2. PT primary 1
5. Dig. in/out.
System OUT fail-safe
3. PT secondary 1 Pulser OUT non-fail-safe
Menu 6.5: Response values
Pulser IN active high
1. U
NGR trip
60 % RESET IN active high
2. I
NGR trip
60 % TEST IN active high
3. > R
NGR
150 % 6. Buzzer
Buzzer alarm off
Buzzer test on
