22
DTC SPN FMI Description
Go to the Service
Action Code List in
Table 4B
12320782 188 14
J1939 Signal: Missing Engine
Conguration(EC1)Message
N
12386830 701 14
J1939 Signal: Missing Auxiliary Input/
Output Status (AUXIO1) Message
N
12451842 190 2
J1939 Signal: Invalid Electronic Engine
Control (EEC1) Engine Speed
N
12451849 190 9
J1939 Signal: Electronic Engine Control
(EEC1) Engine Speed Not Available
N
12451854 190 14
J1939 Signal: Missing Electronic Engine
Control (EEC1) Message
N
12451859 190 19
J1939 Signal: Error In Electronic Engine
Control (EEC1) Engine Speed
N
12648969 705 9
J1939 Signal: Auxiliary Input/Output Status
(AUXIO) Trailer Connected Not Available
N
12648979 705 19
J1939 Signal: Error In Auxiliary Input/
Output Status (AUXIO) TR Connected
N
12714505 706 9
J1939 Signal: Auxiliary Input/Output Status
(AUXIO) Trailer ABS Detect Not Available
N
12714515 706 19
J1939 Signal: Error In Auxiliary Input/
Output Status (AUXIO) TR ABS Detect
N
12780034 707 2
J1939 Signal: Auxiliary Input/Output Status (AUXIO)
Trailer ABS Detected Not Fully Operational
N
12780041 707 9
J1939 Signal: Auxiliary Input/Output Status
(AUXIO) Trailer ABS Operational Not Available
N
12780051 707 19
J1939 Signal: Error In Auxiliary Input/Output
Status (AUXIO) TR ABS Operate
N
13508354 8142 2
J1939 Signal: Invalid Forward Lane Image
(FLI2) Forward Lane Imager Status
X
13508361 8142 9
J1939 Signal: Forward Lane Image (FLI2)
Forward Lane Imager Status Not Available
X
13508366 8142 14
J1939 Signal: Missing Forward Lane
Image (FLI2) Message
X
13508371 8142 19
J1939 Signal: Error In Forward Lane Image
(FLI2) Forward Lane Imager Status
X
13566995 1231 19 CanBusError:PhysicalErrorBusO󰀨 Y
14353410 1243 2
J1939 Signal: Electronic Brake Controller
(Ebc1) ABS Not Fully Operational
U
14353417 1243 9
J1939 Signal: Electronic Brake Controller
(EBC1) ABS Operate Not Available
U
14353422 1243 14
J1939 Signal: Missing Electronic Brake
Controller (EBC1) Message
U
14353427 1243 19
J1939 Signal: Error In Electronic Brake
Controller (EBC1) ABS Operate
U
14681602 1760 2
J1939 Signal: Invalid Combination Vehicle Weight
(CVW) Gross Combination Vehicle Weight
U
Table 4A – Diagnostic Trouble Codes (DTCs), SPN, and FMI
