GrandPrix (GP-7 Series) Two-Post Lifts 9 P/N 5900209 — August 2018 — Rev. C2
Model
GP-7LCS GP-7LC GP-7
Lifting capacity 7,000 lbs / 3,175 kg
E – Height overall 106.5" / 2,703 mm 118.5" / 3,008 mm 150" / 3,814 mm
F – Width overall 124.7" / 3,168 mm
G - Outside posts 119.5" / 3,034 mm
J - Floor to Trip Stop Tube 97.5" / 2,479 mm 109.5" / 2,784 141.25" / 3,590 mm
H – Inside posts 110.1" / 2,798 mm
K - Reach (front arm min) 27" / 688 mm
K - Reach (front arm max) 44.6" / 1,133 mm
L - Reach (rear arm min) 28" / 711 mm
L - Reach (rear arm max) 47" / 1,194 mm
D - Minimum pad height 4.5" / 113 mm
A – Rise 53.25" / 1,350 mm 63.25" / 1,604 mm 73.5" / 1,864.5 mm
B – Rise + pad 57.5" / 1,463 mm 67.5" / 1,717 mm
77.75" / 1,977.5 mm
C – Rise + pad + adapter 65.75" / 1,673 mm 75.75" / 1,927 mm
86.25" / 2,190.6 mm
I - Drive-thru width 89.5" / 2,273 mm
Top Trough width 119.4" / 3,034 mm
Motor 220 VAC, 60 Hz, 1Ph
Time to full rise ~45 seconds
Maximum operating
hydraulic pressure
2,940 PSI
Sound 70 dB
