PARTS INVENTORY
QTY. PART(S) DESCRIPTION Part Number WHERE USED CHECK
PARTS BOX
1 Power side cover 5210006 Power side safety ______
1 Power side safety weldment 5210007 Power side safety ______
1 Off side safety cover 5210009 Off side safety ______
1 Off side safety weldment 5210010 Off side safety ______
2 Safety clevis hair pin 5505112 Secure safety clevis pin ______
2 Safety clevis pin 5505113 Safety weldments ______
2 Safety torsion spring 5540130 Safety clevis pin ______
2 Washer 5545255 To tighten safety cable ______
2 M12 hex nut 5535355 To tighten safety cable ______
4 M10 hex head bolt 5530755 Secure safety covers to post ______
4 Washer 5545250 Safety cover bolt ______
4 XP-9/10 lift head pins Lift arms ______
4 Lift pad Assemblies 5210700 Lift arms ______
2 3/8 Romex connectors 5520142 Electrical; motor & overhead sw. ______
1 Overhead micro switch 5525110 Top trough assembly ______
1 Micro switch cable 120” 5525215 Overhead micro switch ______
2 6-32 slot head bolt 5530117 Secure overhead micro switch ______
2 6-32 Hex nut 5535190 Secure overhead micro switch ______
12 Anchor bolts 3/4 x 5 5530450 Secure posts to floor ______
24 C-Shims 5545535 Level posts ______
4 M8 hex head bolts 5530753 Mount power unit to post ______
4 Lock washers 5545254 Mount power unit to post ______
4 M8 hex nut 5535356 Mount power unit to post ______
2 3/4-12 hex nylock nut 5535353 Equalizer cable nut ______
2 3/4” flat washer 5545253 Equalizer cable washer ______
4 M10 hex head bolt 5530751 Secure top trough assy ______
4 M10 nylock nut 5535350 Secure top trough assy ______
4 Washer 5545251 Secure top trough assy ______
1 3/8” power unit fitting 5550183 Hydraulic fitting for power unit ______
2 1/4” cylinder fittings 5550113 Hydraulic fitting for cylinders ______
1 1/4 to 3/8” bulkhead fitting 5550185 Hydraulic tee fitting to cylinders ______
1 1/4” x 90-1/2” hydraulic hose 5570832 Power side cyl hose all models ______
1 3/8” x 48” hydraulic hose 5570102 Power unit hose all models ______
4 3” lift pad extension 5746390 Raise the height of lift pad ______
4 6” lift pad extension 5746395 Raise the height of lift pad ______
1 1/4” crossover hose see table Crossover to offside cylinder ______
1 Safety cable see table Cable to release safety ______
2 Equalizer cables see table Cable to level lift arms ______
1 Can Spray Paint Touch Up Paint ______
1 Instruction Manual Instruction Manual ______
1 ALI Safety Instructions Safety Instructions ______
4
BE SURE TO TAKE A COMPLETE INVENTORY
OF PARTS PRIOR TO INSTALLATION
When removing the lift from shipping angles pay close attention as the posts
can slide and can cause injury. Prior to removing the bolts make sure the
posts are held securely by a fork lift or some other heavy lifting devise.
