39
LIFT OPERATION SAFETY (CONT’D)
4. Position vehicle for proper weight distribution arms
under vehicle to allow adapters to contact at the
manufacturer’s recommended pick up points.
5. If the specific vehicle lift points are not identified, refer
to the VEHICLE CENTER OF BALANCE instructions
found on our website at:
www.bendpak.com/support/balancing-safety/
6. Push the RAISE button or rotate the control switch on
the power unit.
7. Stop before making contact with vehicle. Check arm
restraint pins for engagement. If required, slightly move
arm to allow restraint gear and pawl to mesh. DO NOT
hammer arm restraint pin down as this will damage the
restraint gear teeth.
8. Raise vehicle until tires clear the floor.
Fig. 19.2
TYPICAL LIFTING POINTS
Fig. 19.3
MANY SPECIALTY OR MODIFIED VEHICLES
CANNOT BE RAISED ON A TWO-POST FRAME
ENGAGING LIFT. CONTACT VEHICLE
MANUFACTURER FOR RAISING OR JACKING
DETAILS.
NOTE:
ALLOW (2) SECONDS BETWEEN MOTOR STARTS.
FAILURE TO COMPLY MAY CAUSE MOTOR
BURNOUT.
