Page #74 background image
XPR-10 Series Two-Post Lifts 74 P/N 5900951Rev. D May 2019
Troubleshooting
This section describes how to troubleshoot your Lift.
Note: If your Lift is not functioning correctly, you must take it out of service until it is fixed.
Important: All repair work
must
be done by qualified personnel.
WARNING The Lift uses electrical energy; if your organization has Lockout/Tagout policies,
make sure to implement them before performing any Troubleshooting.
Issue Action to Take
Lift does not raise or does not lower,
once raised.
Make sure there is sufficient Hydraulic Fluid in the reservoir.
Make sure there is no air in the Hydraulic System.
Make sure none of the Hydraulic Lines are pinched or leaking.
Make sure the Power Unit is getting power.
If the Hydraulic Fluid is dirty, replace it with clean fluid.
Make sure the Lift is not overloaded. Make sure the load on
the Lift is balanced.
Arms move erratically or squeak
when in use.
Move the arms up and down a few times to flush any residual
air from the Hydraulic System.
Lift does not stay up. Make sure to leave the Lift engaged on its Safety Locks.
Check for Hydraulic Fluid leaks.
Vehicle on Lift not level. Make sure Lift is engaged on Safety Locks at the same height.
Make sure the Safety Locks in both Posts are engaged.
If either condition is not met, carefully lower the Vehicle back
down to the ground and raise it again.
Motor not running. Check connection to power source; make sure it is plugged in
and the appropriate voltage.
Check wiring diagram on Power Unit.
Hydraulic Fluid is dirty. Replace the dirty Hydraulic Fluid with clean, approved ATF
fluids, such as Dexron III, Dexron VI, Mercon V, Mercon LV, or
comparable.
Lift makes odd noises. Lubricate hinge points using white lithium grease.
If you continue to have issues with your Lift, take the Lift out of service, then contact your dealer or
BendPak Support at bendpak.com/support, via email at techsupport@bendpak.com, or by
phone at (800) 253-2363.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BendPak XPR-10 Series and is the answer not in the manual?

BendPak XPR-10 Series Specifications

General IconGeneral
Capacity10, 000 lbs
Rise Time45 seconds
Voltage220V
Motor2 HP
Minimum Height4.5 inches
Overall Height145" / 3, 683 mm
