Benelli 302R User Manual

11 - 12
REAR SHOCK ABSORBER
Step the rear brake pedal to brake the rear wheel.
Brake light will turn on while rear brake is in use.
REAR BRAKE PEDAL
Slow down the vehicle
when turning to the low
gear. Revving up the
engine slightly to shift
gears in more smooth
way to avoid damaging
gears.
SHIFT PEDAL
Each shock absorber is equipped with a spring
preload adjusting ring the spring of the rear wheel
can be adjusted in compliance with the driver's
weight and loading condition, driving method and
road conditions. Adjust when vehicle it is stable on
the main stand or side stand, turn the preload ring to
the place required.
Rear Brake Pedal
WARNING
!
Do not over fill the fuel tank. Do not make fuel
splashes on hot engine.
Please stop the engine and turn the ignition key
to " " (Off) position when you need to refuel.
Do not forget to lock the fuel tank cover after
adding the fuel in case of evaporation to the air,
which is a waste of energy and would pollute
the environment.
Recommended fuel:
Regular Unleaded Gasoline Only
Fuel tank capacity:
14 L
TORQUE VALUE
Upper fixing bolt: 37-44N.m
Lower fixing bolt: 22-29N.m
Adjustable
STIFFER
STIFFER
SOFTER
SOFTER
Locknut
Adjusting nut
Adjusting nut
fuel tank cover
1
N 6
2
5
3 4

Benelli 302R Specifications

Engine Specifications

maximum torque	27.4 N.m/9000 r/min
bore × stroke	ø65.0×45.2
displacement	265 MN-A
compression ratio	11.5:1
maximum power	28 kW/11000 r/min

Tires

front tire	110/70-R17
rear tire	150/60-R17

Fuel and Ignition

fuel tank capacity	14 L
fuel type	Regular unleaded gasoline
ignition system type	TLI

Brakes

front brake type	Disk Brake
rear brake type	Disk Brake

Weight and Dimensions

length	2150 mm
width	745 mm
height	1115 mm
wheelbase	1410 mm
dry weight	188 kg
